Designed for the effortless production of dental prosthetics, Roland DG dental mills deliver quality, efficiency and value in a compact, user-friendly device. Ideal for labs or office environments, the open architecture of the DWX series allows you to work with the latest materials, CAD/CAM software and scanners, without the need to rely on a single source.
Built for precision, error-free milling, you don’t need any machine expertise to operate the DWX-51D. With touch-button controls and automated milling features, the production of high-quality bridges, crowns, inlays, onlays, abutments and other restorations out of 98 mm discs and blocks has been made virtually fool proof.
For thirty years, Roland DG has been the trusted provider of milling machines that are built to last. The DWX-51D 5-Axis Dental Milling Machine is no exception. After extensive research in which lab technicians were asked what they needed in a production mill, the DWX-51D was developed to enhance user experience, maximize ease-of-use and improve output quality. Built with a simple and modern design, the DWX-51D looks as effortless as it operates.
The DWX-51D is a smooth and steady ball screw-driven machine capable of milling complex restorations. It operates on X,Y, and Z axes – simultaneously rotating blocks and discs. Tilting on the B axis it supports deep undercuts and the complex milling of large arch restorations and other full-mouth prosthetics.
A unique inner structure with spacious airflow supports comfortable operation, while an automatic dust collection feature boasts a powerful vacuum for clean usage and calibration. An ionizer removes static, ideal for milling PMMA material.
The open architecture of the DWX-51D allows you to work with the latest materials, CAD/CAM software and scanners, without needing to rely on a single source.
The DWX-51D is a smooth and steady ball screw-driven machine capable of milling complex restorations. It operates on X,Y, and Z axes – simultaneously rotating blocks and discs. Tilting on the B axis it supports deep undercuts and the complex milling of large arch restorations and other full-mouth prosthetics.
Complex controls associated with CNC milling have been replaced by a user-friendly Virtual Machine Panel (VPanel) that automatically starts the milling process, conducts machine diagnostics and operates milling calibration from your computer.
The new C-clamp on the DWX-51D requires the adjustment of only two screws for a simplified set-up. The C-clamp (which includes a torque driver for improved clamping consistency) also provides exact alignment and uniformity, resulting in less misalignment issues.
To further automate the milling process and ensure error-free production, users receive e-mail notifications detailing any errors, or when milling is completed, while a color-coded LED light signals machine status.
A material adapter with nine pin-type placement options is included for easy and error free set-up.
VITA certifies the Roland DWX-51D for milling VITA ENAMIC®.
The DWX-51D is the only dry-milling system that, when equipped with our ZBD-100D-HY /50D-HY /30D-HY hybrid tools, is authorized to mill VITA ENAMIC® and produce a full-range of dental prosthetics. Other material brands are also available for milling with the DWX-51D.
The DWX-51D offers unmatched reliability and post-sales support that includes a two-year warranty. Enjoy the benefit of certified service engineers to ensure that your device is always up-and-running and a dedicated online and telephone support staff who can answer all your questions and concerns.
The DWX-51D is equipped to mill industry-standard discs and blocks of these and other popular materials.
Indirect inlays (intracoronal fillings) and Onlays (cusp fillings) can be milled from zirconia or composite materials. The DWX-51D has a 10-station Automatic Tool Changer (ATC) to effortlessly switch to small-bur detailed cutting, ensuring a high-quality product with increased realism.
Roland DG supplies a variety of tools to mill different materials, including diamond-coated burs and ball-end tools designed specifically for precision milling of zirconia and hybrid ceramic.
Copings are quickly and effectively milled by the DWX-51D from a choice of materials for casting, or from materials to which porcelain is applied.
The DWX-51D 5-Axis Dental Milling Machine accurately mills permanent crown restorations that completely cover a tooth, producing zirconia and composite prosthetics with close replication.
The DWX-51D mills a variety of abutments and partial denture supports, including hybrid, screw, glue-based, etc., from a variety of restorative materials.
The DWX-51D can mill single or multiple bridge replacements of any size from a host of compatible materials.
With its 10-station automatic tool changer, the DWX-51D mills bars, partial dentures and other restorations from zirconia with unstoppable ease for outstanding connection strength and precise aesthetics.
| Description | Unit of Measure | Details |
|---|---|---|
| Cuttable material | Zirconia, Wax, PMMA, Composite resin, PEEK, Gypsum | |
| Loadable workpiece shape | Disc type (with step) Pin type |
Step section: 98.5 mm (diameter), height 10mm Body section: 95 mm (diameter), height max. 60mm Pin diameter: 6 mm |
| Operating speed | XYZ axis: | 6 to 1800 mm/min. (0.24 to 70.9 in./min.) |
| Spindle motor | Brushless DC motor | |
| Spindle speed | 6,000 to 30,000 rpm | |
| Rotary axis travel angle | A axis B axis |
±360° ±30° |
| Number of burs housed | 10 | |
| Attachable bur | Shank diameter Length |
4 mm 40 to 55 mm |
| Compatible compressed air | 0.02 to 0.2 MPa | |
| Interface | USB | |
| Control command set | RML-1, NC code | |
| Power requirements | AC 100 to 240 V ± 10%, 50/60 Hz , 2.0 A (overvoltage category II, IEC 60664-1) | |
| Power consumption | Approx. 200 W | |
| Operating noise | During operation During Standby |
70 dB (A) or less (when not cutting) 45 dB (A) or less |
| External dimensions | Width x Depth x Height | 495 × 660 × 600 mm (19.5 × 26.0 × 23.6 in.) |
| Weight | 67 kg (147.7 lbs.) | |
| Installation environment | Indoor use, Altitude Temperature Humidity Ambient pollution degree Short-term temporary overvoltage Long-term temporary overvoltage |
Up to 2000 m (6,562 ft.) 5 to 40 °C (41 to 104 °F) 35 to 80% (no condensation) 2 (as specified by IEC 60664-1) 1440 V 490 V |
| Included items | Power cord, USB cable, Regulator, Air hose, Pin-type material adapter, Automatic correction jig, Detection pin, Torque screwdriver, Milling bur holders, Mounting screws, Hexagonal screwdriver, T-shaped hexagonal screwdriver, Dust collection hoses, Dust collection hose adapter, spanner, Roland Software Package CD, Torque screwdriver, Ferrite core, Manuals |
|
| System requirements for USB connection | Operating system USB cable |
Windows Vista®, Windows® 7/8/8.1/10 (32 or 64 bit) Use the included USB cable |
Built for precision, error-free milling, you don’t need any machine expertise to operate the DWX-51D. With touch-button controls and automated milling features, the production of high-quality bridges, crowns, inlays, onlays, abutments and other restorations out of 98 mm discs and blocks has been made virtually fool proof.
For thirty years, Roland DG has been the trusted provider of milling machines that are built to last. The DWX-51D 5-Axis Dental Milling Machine is no exception. After extensive research in which lab technicians were asked what they needed in a production mill, the DWX-51D was developed to enhance user experience, maximize ease-of-use and improve output quality. Built with a simple and modern design, the DWX-51D looks as effortless as it operates.
The DWX-51D is a smooth and steady ball screw-driven machine capable of milling complex restorations. It operates on X,Y, and Z axes – simultaneously rotating blocks and discs. Tilting on the B axis it supports deep undercuts and the complex milling of large arch restorations and other full-mouth prosthetics.
A unique inner structure with spacious airflow supports comfortable operation, while an automatic dust collection feature boasts a powerful vacuum for clean usage and calibration. An ionizer removes static, ideal for milling PMMA material.
The open architecture of the DWX-51D allows you to work with the latest materials, CAD/CAM software and scanners, without needing to rely on a single source.
The DWX-51D is a smooth and steady ball screw-driven machine capable of milling complex restorations. It operates on X,Y, and Z axes – simultaneously rotating blocks and discs. Tilting on the B axis it supports deep undercuts and the complex milling of large arch restorations and other full-mouth prosthetics.
Complex controls associated with CNC milling have been replaced by a user-friendly Virtual Machine Panel (VPanel) that automatically starts the milling process, conducts machine diagnostics and operates milling calibration from your computer.
The new C-clamp on the DWX-51D requires the adjustment of only two screws for a simplified set-up. The C-clamp (which includes a torque driver for improved clamping consistency) also provides exact alignment and uniformity, resulting in less misalignment issues.
To further automate the milling process and ensure error-free production, users receive e-mail notifications detailing any errors, or when milling is completed, while a color-coded LED light signals machine status.
A material adapter with nine pin-type placement options is included for easy and error free set-up.
VITA certifies the Roland DWX-51D for milling VITA ENAMIC®.
The DWX-51D is the only dry-milling system that, when equipped with our ZBD-100D-HY /50D-HY /30D-HY hybrid tools, is authorized to mill VITA ENAMIC® and produce a full-range of dental prosthetics. Other material brands are also available for milling with the DWX-51D.
The DWX-51D offers unmatched reliability and post-sales support that includes a two-year warranty. Enjoy the benefit of certified service engineers to ensure that your device is always up-and-running and a dedicated online and telephone support staff who can answer all your questions and concerns.
The DWX-51D is equipped to mill industry-standard discs and blocks of these and other popular materials.
Indirect inlays (intracoronal fillings) and Onlays (cusp fillings) can be milled from zirconia or composite materials. The DWX-51D has a 10-station Automatic Tool Changer (ATC) to effortlessly switch to small-bur detailed cutting, ensuring a high-quality product with increased realism.
Roland DG supplies a variety of tools to mill different materials, including diamond-coated burs and ball-end tools designed specifically for precision milling of zirconia and hybrid ceramic.
Copings are quickly and effectively milled by the DWX-51D from a choice of materials for casting, or from materials to which porcelain is applied.
The DWX-51D 5-Axis Dental Milling Machine accurately mills permanent crown restorations that completely cover a tooth, producing zirconia and composite prosthetics with close replication.
The DWX-51D mills a variety of abutments and partial denture supports, including hybrid, screw, glue-based, etc., from a variety of restorative materials.
The DWX-51D can mill single or multiple bridge replacements of any size from a host of compatible materials.
With its 10-station automatic tool changer, the DWX-51D mills bars, partial dentures and other restorations from zirconia with unstoppable ease for outstanding connection strength and precise aesthetics.
| Description | Unit of Measure | Details |
|---|---|---|
| Cuttable material | Zirconia, Wax, PMMA, Composite resin, PEEK, Gypsum | |
| Loadable workpiece shape | Disc type (with step) Pin type |
Step section: 98.5 mm (diameter), height 10mm Body section: 95 mm (diameter), height max. 60mm Pin diameter: 6 mm |
| Operating speed | XYZ axis: | 6 to 1800 mm/min. (0.24 to 70.9 in./min.) |
| Spindle motor | Brushless DC motor | |
| Spindle speed | 6,000 to 30,000 rpm | |
| Rotary axis travel angle | A axis B axis |
±360° ±30° |
| Number of burs housed | 10 | |
| Attachable bur | Shank diameter Length |
4 mm 40 to 55 mm |
| Compatible compressed air | 0.02 to 0.2 MPa | |
| Interface | USB | |
| Control command set | RML-1, NC code | |
| Power requirements | AC 100 to 240 V ± 10%, 50/60 Hz , 2.0 A (overvoltage category II, IEC 60664-1) | |
| Power consumption | Approx. 200 W | |
| Operating noise | During operation During Standby |
70 dB (A) or less (when not cutting) 45 dB (A) or less |
| External dimensions | Width x Depth x Height | 495 × 660 × 600 mm (19.5 × 26.0 × 23.6 in.) |
| Weight | 67 kg (147.7 lbs.) | |
| Installation environment | Indoor use, Altitude Temperature Humidity Ambient pollution degree Short-term temporary overvoltage Long-term temporary overvoltage |
Up to 2000 m (6,562 ft.) 5 to 40 °C (41 to 104 °F) 35 to 80% (no condensation) 2 (as specified by IEC 60664-1) 1440 V 490 V |
| Included items | Power cord, USB cable, Regulator, Air hose, Pin-type material adapter, Automatic correction jig, Detection pin, Torque screwdriver, Milling bur holders, Mounting screws, Hexagonal screwdriver, T-shaped hexagonal screwdriver, Dust collection hoses, Dust collection hose adapter, spanner, Roland Software Package CD, Torque screwdriver, Ferrite core, Manuals |
|
| System requirements for USB connection | Operating system USB cable |
Windows Vista®, Windows® 7/8/8.1/10 (32 or 64 bit) Use the included USB cable |
